Honeywell Q340A Universal Thermocouple Kit – 30″ Length, Push-In Clip, For Pilot Burners in Gas Furnaces and Water Heaters

Honeywell Q340A Universal Thermocouple Kit – 30″ Length, Push-In Clip, For Pilot Burners in Gas Furnaces and Water Heaters

Condition: Used. May show signs of wear or minor residue from prior installation.
The Honeywell Q340A Universal Thermocouple Kit is a robust and reliable safety component designed for use in standing pilot gas-fired heating appliances, such as furnaces, water heaters, and boilers. The thermocouple generates a millivolt signal in response to heat from a pilot flame, providing safety shutdown capability by interrupting gas flow if the pilot goes out. The Q340A kit is engineered to replace a wide variety of thermocouple models and includes adapters to facilitate universal installation.

This thermocouple is 30 inches long, suitable for most standard residential applications. It features a durable copper sheath for long service life and consistent signal output. The kit includes necessary hardware for mounting and connection to most pilot assemblies, making it an ideal replacement solution in the field.

🔧Features
Length: 30 inches (762 mm)
Connection Type: Universal push-in clip and nut adapter kit included
Sheath Material: Copper
Mounting Hardware: Included
Temperature Rating: Designed for high-heat environments near open pilot flames
Signal Output: Generates 20–30 millivolts DC when properly heated
Compatibility: Works with most standing pilot gas valves requiring a thermocouple

🛠️ Applications
This thermocouple is commonly used in:
Residential gas furnaces
Gas-fired water heaters
Boilers
Wall heaters and space heaters with standing pilots
Commercial kitchen appliances with pilot systems

🔁 Cross-Referenced Models
The Honeywell Q340A Universal Thermocouple is a replacement for or compatible with:
Robertshaw 1980 Series
White Rodgers H06E-36
Johnson Controls K15 Series
Uni-Line 1980-030
Norton 3090TC
Husky TC30
Camco 09231

🔄 Comparable Products
Robertshaw 1980-036 (36” Universal Thermocouple)
White Rodgers 3A18-301 (30” Thermocouple with Adapter Fittings)
Supco TC30 (30” Universal Thermocouple)
Johnson Controls K15-30
Camco 09231 (30” Thermocouple for Gas Appliances)

🧩 Assembly and System Compatibility
The Q340A is commonly integrated into the pilot assembly of gas-powered heating systems. It is compatible with many Honeywell gas valves, such as:
Honeywell VR8200A/B, VR8300A/B, VR8345M, and others
Also compatible with equivalent pilot assemblies in brands like Lennox, Rheem, Trane, Carrier, and York that use millivolt thermocouple inputs

Trademark Disclaimer:
All product and company names are trademarks™ or registered® trademarks of their respective holders. Use of them does not imply any affiliation with or endorsement by them.

🔁 Related
Universal thermocouple 30 inch
Gas pilot thermocouple
Flame sensor replacement
Millivolt generator safety device
30″ copper thermocouple for furnace

📈 Common Requests:
“How to install Honeywell Q340A thermocouple in a furnace?”
“Is Q340A compatible with Robertshaw 1980-036?”
“Replace gas water heater thermocouple – 30 inch universal”
“How many millivolts should my thermocouple produce?”
“Gas pilot won’t stay lit – thermocouple replacement needed”
