Residential and commercial condensing unit fan motor to meet manufacturer’s requirements.
- 140F Ambient Design
- Bearing have All Angle Thrust System
- Class B Insulation
- Designed for use with 370V capacitors
- Extended Studs
- 36″ Leads
- Hubless Lead End
- Drain Holes Both Ends
- Reversible Rotation
- Automatic Reset Thermal Overload Protector
- Continuous duty
Model number: CECOMINOD075128
- Type: Permanent Split Capacitor
- Voltage: 208/230v
- Horse Power: 1/3
- RPM: 1075
- Phase: 1
- Amperage: 2
- Enclosure Type: Totally Enclosed Air Over (TEAO)
- Rotation: CCW Lead End Reversible
- Frame 48Y
- Capacitor: 7.5MFD/370VAC
- Shaft Diameter: 1/2″
- Shaft Length: 5″
Dimensions: 13.2 x 7.2 x 7.1 (package)
Ship Weight: 13 lbs.
Brand: US Motors
Model: K055WMT1281012B K55HXWMT-1281
UPC: 786382001704
| Weight | 11 lbs |
|---|---|
| Dimensions | 11 × 11 × 11 in |
| Horse Power (HP) | 1/3 |
| Voltage | 208-230V |
| Speed | 1075 RPM |
