Honeywell 5808W3 Photoelectronic Smoke And Heat Detector


1 in stock

UPC: 781410807174 5808W3

Honeywell 5808W3 Photoelectronic Smoke And Heat Detector

New: A brand-new, unused, undamaged item in its original packaging.

The 5808W3 photoelectronic smoke/heat detector with built-in wireless transmitter is intended for use with wireless alarm systems that support 5800 series devices.
The 5808W3 smoke/ heat detector can be used with any 5800 series wireless receiver/ transceiver for residential installations. For commercial installations, the 5881ENHC or the 5883H receiver is required. The transmitter can send alarm, tamper, maintenance (when control panels are equipped to process maintenance signals), and battery condition messages to the system’s receiver. The maintenance signal fully complies with the sensitivity test requirement specified in NFPA 72, and is approved by UL.
The 5808W3 incorporates a state-of-the-art optical sensing chamber and an advanced microprocessor. The microprocessor allows the detector to automatically maintain proper operation at factory calibrated detection levels, even when sensitivity is altered due to the presence of contaminants settling into the unit’s smoke chamber. In order for this feature to work properly, the chamber must never be opened while power is applied to the smoke detector. This includes cleaning, maintenance or screen replacement. All models also feature a restorable, built-in, fixed temperature (135°F) thermal detector and is also capable of sensing a pre-freeze condition if the temperature is below 41°F.


Power Source: One 3-volt CR123A Lithium Battery (included). (Replace with Duracell DL123A, Sanyo CR123A,
Panasonic CR123A or ADEMCO 466.)
Height: 2.3 inches (58 mm)
Diameter: 5.3 inches (135 mm) with mounting base
Weight: 8.5 oz. (241 g) without battery
Operating Ambient Temperature Range: 32° to 100°F (0° to 38°C)
Operating Humidity Range: 0% to 95% Relative Humidity
Heat Sensor: 135° F Fixed T
Brand: Honeywell
Model: 5808W3
SKU: 5808W3
UPC: 781410807174

The Honeywell 5808W3 Photoelectronic Smoke and Heat Detector is a versatile and advanced fire detection device. Here are its main uses, advantages, and convenient features:

Purpose and Use:

1. Fire Detection: The Honeywell 5808W3 is primarily used for fire detection in residential and commercial settings. It is designed to quickly and accurately detect the presence of smoke and heat, providing early warnings of potential fires.

2. Photoelectric Smoke Sensing: The device utilizes photoelectric smoke sensing technology to detect the presence of smoke particles in the air. This technology is effective in detecting slow, smoldering fires, which can be particularly dangerous.

3. Heat Detection: In addition to smoke detection, the 5808W3 features heat detection capabilities. It can sense rapid increases in temperature or rate of temperature rise, providing a dual approach to fire detection.

4. Residential and Commercial Applications: This detector is suitable for use in both residential homes and commercial buildings, making it a versatile choice for a wide range of environments.


1. Dual Detection: The Honeywell 5808W3 combines photoelectric smoke detection with heat detection, offering a comprehensive approach to fire detection. This increases its accuracy and reduces the risk of false alarms.

2. Wireless Connectivity: The device is wireless, allowing for easy installation and flexibility in placement. It can be integrated into wireless alarm systems and connected to a central monitoring station.

3. Long Battery Life: The 5808W3 is designed to have a long battery life, reducing the need for frequent battery replacements.

4. LED Indicator: The device features a visible LED indicator that provides status information, making it easy to check the device’s operational status.

5. Tamper Detection: It includes tamper detection features to alert users if the device is tampered with or removed.

6. Hush Feature: The detector typically includes a hush feature, allowing users to temporarily silence the alarm in non-emergency situations.

7. Compatibility: It is compatible with Honeywell security and alarm systems, enhancing its integration into existing security setups.

Convenient Features:

1. Easy Installation: The wireless design simplifies installation, eliminating the need for complex wiring.

2. Interconnectivity: Multiple 5808W3 detectors can be interconnected, so when one detects a fire, all interconnected units sound an alarm, providing additional safety.

3. Voice Alerts: Some models of the 5808W3 may offer voice alerts in addition to audible alarms, providing clear instructions to occupants.

4. Maintenance Alerts: Some models may provide maintenance alerts, such as low battery warnings, ensuring the device remains operational.

In summary, the Honeywell 5808W3 Photoelectronic Smoke and Heat Detector is a versatile fire detection device suitable for residential and commercial applications. Its dual detection capabilities, wireless connectivity, and additional features make it a reliable and convenient choice for enhancing fire safety and early detection in a variety of environments.

Compatibility with Smart Home Systems:

Honeywell 5808W3 Photoelectronic Smoke and Heat Detector is compatible with many smart home systems and security platforms. Its wireless connectivity and compatibility with standard alarm system protocols make it an excellent choice for integration into a smart home ecosystem. Here’s how it can work with smart home systems:

  1. Centralized Control: When integrated into a smart home system, the 5808W3 can be centrally controlled and monitored through a smart home hub or security panel. This allows homeowners to receive alerts and notifications on their smartphones or other smart devices.
  2. Home Automation: Smart home systems often include automation features. When smoke or heat is detected by the 5808W3, it can trigger automation routines, such as turning on lights, unlocking doors, or shutting down HVAC systems to minimize the spread of smoke in the event of a fire.
  3. Voice Assistants: Some smart home systems and hubs are compatible with voice assistants like Amazon Alexa or Google Assistant. Users can receive voice notifications and control the device using voice commands when integrated with these platforms.
  4. Mobile Apps: Many smart home security systems offer mobile apps that allow users to remotely monitor and control their devices, including the 5808W3. This provides real-time information and control from anywhere.
  5. Integration with Security Systems: The 5808W3 can be integrated into a broader security system, allowing it to communicate with other sensors, cameras, and alarm devices. In the event of a fire, the system can trigger alarms, notify monitoring centers, and alert homeowners.
  6. Compatibility with Z-Wave and Zigbee: Depending on the specific smart home hub or platform you use, the 5808W3 can be integrated via wireless protocols like Z-Wave or Zigbee, enhancing its connectivity within your smart home network.

Before purchasing the Honeywell 5808W3 for use in your smart home, it’s essential to ensure that it is compatible with your specific smart home hub or security system. Compatibility information should be available in the product documentation or on the manufacturer’s website. Additionally, you may need professional installation or programming to integrate the detector seamlessly into your smart home system, so consulting with a certified installer or technician is advisable.


NL26 E2

Weight 0.8 lbs
Dimensions 6 × 6 × 3 in
