Altronix RB5 Relay Module 6 VDC or 12 VDC DPDT Contacts


1 in stock

UPC: 782239930319 RB5

Altronix RB5 Relay Module 6 VDC or 12 VDC DPDT Contacts

Condition: New. Packaging is Distressed. Brand-new, unused, undamaged item in its original packaging.

The Altronix RB5 Relay Module is a reliable and versatile solution for various switching applications. Its dual voltage operation, high contact rating, and compact design make it an excellent choice for security systems, automation projects, and control systems.
The Altronix RB5 Relay Module is a versatile, reliable relay designed to control various electrical devices. It operates on either 6 VDC or 12 VDC and features Double Pole Double Throw (DPDT) contacts, making it suitable for a wide range of applications in security, automation, and control systems.

Key Features
Dual Voltage Operation: Can operate with both 6 VDC and 12 VDC power sources, providing flexibility in various applications.
DPDT Contacts: Offers two sets of switch contacts, allowing for more complex switching operations.
High Contact Rating: Capable of handling up to 10A at 120VAC or 28VDC, suitable for controlling high-power devices.
Compact Design: Small form factor makes it easy to integrate into existing systems without taking up much space.
Easy Installation: Can be mounted on a snap track or surface, providing flexibility in installation options.

Security Systems: Ideal for controlling door locks, alarms, and other security devices.
Automation: Suitable for home and industrial automation tasks requiring reliable switching.
Control Systems: Can be used in various control systems for switching applications.
Access Control: Effective for managing access control devices in commercial buildings.

Related Keywords
Relay module
DPDT relay
Altronix relay
6 VDC relay
12 VDC relay
High-power relay
Security system relay
Automation relay

Brand: Altronix
Model: RB5
Voltage: 6 VDC or 12 VDC
Contacts: Double Pole Double Throw (DPDT)
Contact Rating: 10A @ 120VAC / 28VDC
Dimensions: 2.25″ L x 1.75″ W x 1.25″ H
Weight: 0.1 lbs
Power Consumption: 6 VDC – 51.6 mA; 12 VDC – 37.7 mA
Operating Temperature: -20°C to 49°C (-4°F to 120°F)
Mounting: Snap track mount or surface mount
UPC: 782239930319


Weight 0.2 lbs
Dimensions 4 × 2 × 1.5 in
